SMPS
- Availability: In Stock
SMPS Evaluation board with two single-channel galvanic-isolated gate driver ICs - 1EDI60I12AF and two IGBTs - IKW50N65F5. The major features of the evaluation board are: short circuit protection, current measurement, under voltage lock-out, bootstrap functionality for the high side gate driver, and possibility of separating input and output side.
..SMPS Evaluation board with two single-channel galvanic-isolated gate driver ICs - 1EDI60I12AF and two IGBTs - IKW50N65F5. The major features of the evaluation board are: short circuit protection, current measurement, under voltage lock-out, bootstrap functionality for the high side gate driver, and possibility of separating input and output side.
Product Specification
| Brand | Powertron |
| Efficiency | >85% |
| Rated Power | 60W |
| Weight | 1.2kg. Approx. |
| Dimension | 115x100x55 mm |
| Country of Origin | Made in India |
| DC Voltage | 24VDC |
| Current Range | 0 ~ 2.5A |
| Voltage Range | 90V to 265VAC |
| Model Number | PI-PWR-162 |
| Rated Current | 2.5A |
| Voltage Tolerance | +/- 1% Of Rated Voltage |
| Enclosure Protection | IP-20 |
| Minimum Order Quantity | 25 Piece |
Product Description
Features:
- Wide input supply range.
- Built in EMI filter, low ripple noise.
- Protection: Short circuit / Over load / Over voltage.
- 100% Full Load Burn in test.
- High efficiency, long life and high reliability. Miniature size.
- Customized solution
- Regulated DC Output
- Din Rail / Panel Mounting
- Low Ripple & Noise
- Current Limit
- High Reliability
- High Efficency
